FOTON 6.8m refrigerator truck

Vehicle model: BJ5181XLCY6AKL-01

Trunk dimensions: 6800×2420×2500mm

Wheelbase: 5150mm,

Engine model: Yuchai YCS06300-61

Transmission: Automatic AMT-F8JZ110MM

Rear axle/speed ratio: 8T 340 Han De axle/3.909,

Tires: 275/80R22.5 18PR,

Steel plates: 10/10 + 8,

Cab: High-top double-bed,

Flat floor, Maintenance-free battery, 2, 135A·h, 80A motor, Multi-function steering wheel, Standard rear protection, Day running lights, Electric heating integrated rearview mirror, Airbag type shock absorber driver's seat, Integrated air conditioning with heating and cooling, Fixed speed cruise, Rearview radar, Automatic headlights, 7-inch color screen instrument, Reinforced body, LED headlights.

FOTON Automatic Transmission 6.8m refrigerated truck body configuration: The refrigerator truck is made of internal and external fiberglass materials, with an 8CM thick insulation layer. It uses domestic large negative pressure equipment for one-time molding. The bottom plate uses a 10CM thick reinforced plate with anti-vibration, heat insulation and durable properties. The sides of the trunk are wrapped with right-angle aluminum profiles. The rear door is wrapped with stainless steel, with stainless steel lock pieces and aluminum profiles. The floor inside the box is fully welded with ventilation slots, and a single-sided door is opened.

Optional installation of different brands of refrigeration units, optional installation of meat hook rails, optional installation of hydraulic tailboards.

Characteristics of FOTON Automatic Transmission 6.8m refrigerated truck

1. Strong Insulation Performance

Refrigerated vehicles have a certain insulation performance, mainly including two aspects: truck body insulation and window sealing performance. The truck body insulation mainly uses materials such as polyurethane and polystyrene board, which have good heat insulation properties and can maintain a constant temperature inside the refrigeator truck. The window sealing performance can effectively prevent outside air from entering the refrigerator truck, ensuring that the temperature inside the vehicle is not affected by the outside environment.

2. Reliable Refrigeration System

The refrigeration system of refrigerated truck uses various compressors or heat pump condensers, featuring high reliability and high refrigeration efficiency. The natural refrigerants gradually replace ozone-depleting refrigerants, making the environmental performance of refrigerated truck better.

3. Reasonable Space Structure

The space structure of refrigerated truck needs to be reasonably designed to fully utilize the space, ensuring that the goods are in a stable state inside the truck and will not slide or collide, guaranteeing the stability of goods transportation. In addition, it is necessary to set up partitions, pull doors, etc., to facilitate the loading, unloading and storage of goods.

Refrigerator truck made delivery in batch:

IV. With Safety Protection Measures

The refrigerated vehicle is equipped with security protection measures such as anti-theft, fire prevention, and radiation protection, which can ensure the safety of the goods during transportation. In conclusion, refrigerated trucks have good insulation performance, reliable refrigeration systems, reasonable space structure, and safety protection measures. They are suitable for the cold chain transportation field and can ensure the safe transportation of goods such as food, medicine, chemicals, and electronic products.
