Chengli Special Automobile Co., Ltd is an important branch of CLW group with registered capital 100, 000, 000 RMB(14 millions US Dollars) and total capital 6, 000, 000, 000(840 millions US Dollars). Located in Suizhou city, hubei province, central China, Chengli Special Automobile Co., Ltd is one of the largest manufacturers authorized by National Ministry of Industry and Information for production of 800 types of special trucks and export Center of Trucks and Spare parts identified by Hubei Province Government, such as Water Tank Truck, Insulation Truck and Milk Truck, Sewage Suction Truck, Garbage Truck, Man lift Truck/Aerial Platform Truck, Truck with Crane, Fuel Truck/Trailers, Chemical Tanker Delivery Truck, Bulk Cement Truck, Concrete Mixer Truck, Fire Truck, Dump Truck, Van Truck/Refrigerated Truck, Wrecker/Tow Truck, Flatbed Truck/Low Bed, Tractor, LPG Tank/Truck/Trailer/Skid Station, Road Sweeper/Cleaning Truck, Ambulance Trucks......
Origin: Suizhou China
Brand: CLW
Emission standard: EURO 2/3/4/5/6
Steering wheel: LHD/RHD
Chassis: Isuzu/ Sinotruck/Shacman/Dongfeng/CLW/JAC/Foton/JMC
Road sweeper truck mainly used for ground cleaning, road curb edge cleaning, road curb cleaning and ground watering. It is suitable for various climates and different road surfaces for cleaning operations. It is more suitable for cleaning and dust removal in places such as squares, highways, residential areas, parking lots, docks, airports, stations, cement plants, power plants, etc.
Dongfeng 5m3 road sweeper truck parameters:
| outer diameter | 6200*2000*2590mm | GVW | 7360kg |
| curb weight | 5100kg | rated loading capacity | 2130kg |
| axle loading capacity | 2640/4720mm | passengers | 2 |
| max speed | 110km/h | emission standard | EURO 6 |
Dongfeng 5m3 road sweeper truck body parameters:
| Water tank | water tank volume | 1.5 m³ |
Waste tank | Waste tank volume | 4 m³ |
Waste tank tilting angle | ≥46° | |
Discharge door opening angl | ≥85° | |
Auxiliary engine | Brand | JMC |
Power | 87hp | |
Hydraulic system | Type | electrical control |
Main components | Gear pump, hydraulic motor, hydraulic cylinder, electromagnetic valve | |
Pressure | 16 MPa | |
Hydraulic oil tank volume | 60L | |
Hydraulic oil temperatur | 60 ˚C | |
Electric system | typ | DC12 V |
Voltage | 12V | |
Battery | 12V | |
Water spraying system | Main components | Electric diaphragm pump, water filter, nozzle, etc. |
Sweeping device | type | equipped with 4 rotating sweeping discs in the middle, driven by a hydraulic motor. The right front part can be independently controlled and has a function for avoidance and recovery. |
Diameter of the sweeping disc | 850 mm | |
Sweeping disc angle | Inclination: 4 - 6 degrees Outward tilt: 4 - 7 degrees | |
Suction disc | type | Single suction port, hydraulic control, spring suspension. |
Diameter of the suction port | 200mm | |
Sweeping performance | Efficiency | ≥95% |
Maximum inhalation particle size | 120 mm | |
Seeping width | 2.6 m | |
Max sweeping capacity | 13000㎡/h-52000㎡/h | |
Extension size of the sweeping disc | ≥400 mm | |
Speed while sweeping | 3-20 km/h |
